Lithium Iron Phosphate Battery (LiFePO4 Battery)

Lithium Iron Phosphate Battery (LiFePO4 Battery)
  • Lithium Iron Phosphate Battery (LiFePO4 Battery)
  • Lithium Iron Phosphate Battery (LiFePO4 Battery)
  • Lithium Iron Phosphate Battery (LiFePO4 Battery)

    • Lithium Iron Phosphate Battery (LiFePO4 Battery)

    Powering an array of consumer technologies, the lithium iron phosphate battery (LiFePO4 battery) is designed to be as safe as possible. It provides protection against short circuits, overcharging, overdischarging, overcurrents and high temperatures, making it ideal for use in street lamps, monitoring systems, UPS and off-grid systems.

    Request a Quote
    Features
    • The efficiency of charge and discharge is extremely high, with an efficiency level of 90% or higher when in the discharge state.
    • Superior safety standards.
    • The lithium iron phosphate battery boasts a significantly longer cycle life than that of other batteries, with the ability to withstand 5000 charges or more. Under standard charging conditions of five hours, the battery's life is extended to up to 3000 cycles.
    • Superior temperature performance.
    • The capacity of the lithium iron phosphate battery is exceptionally high.
    • No memory effect
    • Powerful and lightweight.
    Technical Parameters of LiFePO4 Battery
    Nominal voltage 12.8V 12.8V 12.8V 12.8V 12.8V 12.8V
    Nominal capacity 12V20AH 12V30AH 12V40AH 12V45AH 12V50AH 12V60AH
    Charge voltage 14.6V 14.6V 14.6V 14.6V 14.6V 14.6V
    Max. charge current 10A-30A (optional) 10A-50A (optional)
    Peak discharge current 10A-30A (optional) 10A-50A (optional)
    Discharge cut-off voltage 10V 10V 10V 10V 10V 10V
    Internal resistance ≤100mΩ ≤ 100mΩ ≤ 100mΩ ≤ 100mΩ ≤ 100mΩ ≤ 100mΩ
    Weight 2.5KG 4.5KG 4.5KG 6.5KG 7.5KG 8.5KG
    Dimensions (mm) (without controller) 153*98*150 153*98*270 153*98*270 153*98*380 153*98*400 153*98*520
    Charge temperature -0~45℃ (heating plate is optional)
    Discharge temperature -40~50℃
    Storage temperature -20~40℃
    Protection functions Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection
    Applications Street light, monitoring system, UPS, off-grid power system

    Technical Parameters of LiFePO4 Battery Pack (50AH)

    Nominal voltage 51.2V
    Nominal capacity 50AH
    Charge voltage 58.4V
    Charge current 50A
    Peak discharge current 80A
    Discharge cut-off voltage 40V
    Weight 30KG
    Dimensions 245*200*800mm
    Charge temperature 0 ~ 55℃
    Discharge temperature -20 ~ 60℃
    Storage temperature -20 ~ 40℃
    Protection functions Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection

    Technical Parameters of LiFePO4 Battery Pack (100AH)

    Nominal voltage 51.2V
    Nominal capacity 100AH
    Charge voltage 59.2V
    Charge current 50A
    Peak discharge current 50A
    Discharge cut-off voltage 40V
    Weight 40kg
    Dimensions 540-400-150mm
    Charge temperature 0 ~ 45℃
    Discharge temperature -40 ~ 50℃
    Storage temperature -20 ~ 40℃
    Protection functions Short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, temperature protection
    Are you looking for cost-effective solutions for power generation facilities? You can rely on HT SOLAR, a trustworthy manufacturer of solar power generation systems. We are capable of providing comprehensive solar power systems with custom power generation solutions to help customers reduce energy bills while ensuring reliable power supply. Apart from our solar energy systems, we also provide a range of solar system components that are required in solar power plants, such as solar panels, solar inverters, solar batteries and other solar accessories. That is to say, we are one stop source for renewable energy system.
    For over 15 years, our company has cultivated a wealth of experience within various industries, including the Vietnam Cultural Friendship Palace, Cambodia Military Base, Jamaica North-South Highway, Guyana Georgetown Pegasus Hotel, Eritrea Civil Explosive Factory, Ethiopia Coal Mine and more. We strive to deliver the ultimate solution and experience with our high-quality products and professional services, leaving our customers feeling satisfied.
