Crafted from robust aluminum alloy, the body of the wind turbine houses a three-phase AC permanent magnet synchronous generator, providing reliable and efficient power.
| Model | HY-600 | |
| Rated power (W) | 600 | |
| Rated voltage (VDC) | 24 | 48 |
| Max. power (W) | 750 | |
| Start-up wind speed (m/s) | 2.0 | |
| Cut-in wind speed (m/s) | 2.5 | |
| Rated wind speed (m/s) | 12 | |
| Survival wind speed (m/s) | 50 | |
| Rotor diameter (m) | 1.75 | |
| Quality of blades | 5 | |
| Noise (dB) | < 20 dB (based on 5m/s wind speed) | |
| Generator type | Three phase permanent magnet direct drive | |
| Tower connection | Flange connection or bolt-on clamp | |
| Net weight (kg) | 25 | |
| Ambient temperature (°C) | -40~60 | |
| Strong wind protection | Electromagnetic brake, aerodynamic brake | |
| Dimensions | 1250×520×250mm | |
| Weight | HY-600H (3 blades) net weight: 21kg; gross weight: 24kg | |
| HY-600L (5 blades) net weight: 25kg; gross weight: 28kg | ||
| Model | HY-1000L | ||
| Rated power (W) | 1000 | ||
| Rated voltage (VDC) | 24 | 48 | 110 |
| Max. power (W) | 1200 | ||
| Start-up wind speed (m/s) | 2.5 | ||
| Cut-in wind speed (m/s) | 3.0 | ||
| Rated wind speed (m/s) | 12 | ||
| Survival wind speed (m/s) | 50 | ||
| Rotor diameter (m) | 1.95 | ||
| Quality of blades | 5 | ||
| Noise (dB) | < 20 dB (based on 5m/s wind speed) | ||
| Generator type | Three phase permanent magnet direct drive | ||
| Tower connection | Flange connection or bolt-on clamp | ||
| Net weight (kg) | 30 | ||
| Ambient temperature (°C) | -40-60 | ||
| Strong wind protection | Electromagnetic brake, aerodynamic brake | ||
| Dimensions | 1470×530×270mm | ||
| Weight | HY-1000L(5 blades) net weight: 27.5 kg; gross weight: 37kg | ||
