    The high density gel storage battery is a reliable choice for a variety of applications, due to its long service life, wide use temperature range, strong low temperature efficiency, high sealing rate, and minimal self-discharge. It can be utilized in solar (wind) residential systems, off-grid power stations, solar (wind) communication networks, communication base stations, solar (wind) street lamps, mobile energy storage systems, solar-powered traffic lights, and solar building systems, as well as in other emerging new energy fields.

    Request a Quote
    Features

    Our battery products are divided into two series: lead-acid and gel batteries. The gel batteries are especially renowned for their high and low temperature resistance, superb over-discharge recovery ability and extended cycle life.

    • Our patented structure makes connection more straightforward and facilitates buried installation, protecting the pole from corrosion.
    • By utilizing a special alloy and lead paste formula, our battery has a low self-discharge rate, is highly resistant to deep discharges, and also offers superior capacity recovery performance.
    • Our battery has been designed with advanced processes and imported low-resistance raw materials, allowing for efficient charging with low internal resistance and strong acceptance of lower current levels.
    • Wide temperature range of -25°C to 50°C for lead acid and -35°C to 60°C for gel make these batteries suitable for use in both indoor and outdoor applications across a variety of climates.
    • Independently developed nano colloidal electrolytes based on patented multi element rare earth alloys, and nano grade fumed silica originating from Germany. The battery design lifespan is more than 15 years for lead-acid and 18 years for colloids.
    • The battery formula does not contain polluting substances and is not difficult to recycle, coupled with a leak-proof gel electrolyte, making it safe for the environment and delivering strong green protection.
    Technical Parameters
    Model Rated voltage (V) Rated capacity (Ah/10Hr) Dimensions (mm.±3%)
    Length Width Height Total height
    CN(J)-200
    		 2 200 171 106 330 342
    CN(J)-300
    		 2 300 171 151 330 342
    CN(J)-400
    		 2 400 196 171 330 342
    CN(J)- 500
    		 2 500 241 171 330 342
    CN(J)-600
    		 2 600 285 171 330 342
    CN(J)-800
    		 2 800 M3 171 330 342
    CN(J)-1000
    		 2 1000 471 171 330 342
    CN(J)-1200
    		 2 1200 510 175 337 347
    CN(J)-1500
    		 2 1500 318 341 341 351
    CN(J)-2000
    		 2 2000 433 342 341 351
    CN(J)-2500
    		 2 2500 629 346 341 351
    CN(J)-3000
    		 2 3000 629 346 341 351
    6-CN(J)-8
    		 12 8 151 65 95 99
    6-CN(J)-12
    		 12 12 151 100 97.5 102
    6-CN(J)-14
    		 12 14 151 100 97.5 102
    6-CN(J)-20
    		 12 20 181 77 170 175
    6-CN(J)-24
    		 12 24 165 126 175 181
    6-CN(J)-30
    		 12 30 196 165 174 181
    6-CN(J)-40
    		 12 40 196 165 174 181
    6-CN(J)-50
    		 12 50 229 138 210 230
    6-CN(J)-60
    		 12 60 350 166 174 174
    6-CN(J)-65
    		 12 65 350 166 174 174
    6-CN(J)-70
    		 12 70 350 166 174 174
    6-CN(J)-80
    		 12 80 329 172 214 236
    6-CN(J)-90
    		 12 90 329 172 214 236
    6-CN(J)-100
    		 12 100 329 172 214 236
    6-CN(J)-110
    		 12 110 406 174 208 232
    6-CN(J)-120
    		 12 120 406 174 208 232
    6-CN(J)-150
    		 12 150 483 170 240 240
    6-CN(J)-180
    		 12 180 522 240 219 244
    6-CN(J)-200
    		 12 200 522 240 219 244
    6-CN(J)-220
    		 12 220 522 240 219 244
    6-CN(J)-250
    		 12 250 520 269 220 245
    Are you looking for cost-effective solutions for power generation facilities? You can rely on HT SOLAR, a trustworthy manufacturer of solar power generation systems. We are capable of providing comprehensive solar power systems with custom power generation solutions to help customers reduce energy bills while ensuring reliable power supply. Apart from our solar energy systems, we also provide a range of solar system components that are required in solar power plants, such as solar panels, solar inverters, solar batteries and other solar accessories. That is to say, we are one stop source for renewable energy system.
    For over 15 years, our company has cultivated a wealth of experience within various industries, including the Vietnam Cultural Friendship Palace, Cambodia Military Base, Jamaica North-South Highway, Guyana Georgetown Pegasus Hotel, Eritrea Civil Explosive Factory, Ethiopia Coal Mine and more. We strive to deliver the ultimate solution and experience with our high-quality products and professional services, leaving our customers feeling satisfied.
