Features
- Two operating modes: battery-powered mode and non-battery powered mode.
- Solar energy is the primary source of power when there is no battery storage available. When necessary, the mains supply is used to supplement, ensuring the load requirements are met.
- The lithium battery application system is perfectly complemented by the anti-surge and anti-reverse protection at the battery end.
- Choose from three charging modes: solar-only, solar priority, and solar-main power combination.
- Two AC output modes: mains supply priority and inverter output priority.
- Using advanced MPPT technology, this inverter charger boasts a tracking efficiency of at least 99.5%, ensuring maximum power production and efficiency.
- Power Factor Correction (PFC) technology to optimize AC-DC power charging and significantly reduce the strain on power grid capacity.
- SPWM technology produces a pure sine wave output.
- The total charge and discharge current of the battery can be preset, making it ideal for occasions requiring a battery current limit.
- The amount of mains charging can be tailored and adjusted to fit your needs, with the ability to set the rate of mains charging current.
- Self-learning SOC display function
- For those seeking to monitor remotely, pairing the RS485 communication interface with GPRS, WIFI, and other modules can provide an effective solution.
- Using the BMS-Link communication interface and conversion module, it is possible to achieve charge and discharge control via the BMS.
Technical Parameters
| Model | UP2000-HM6022 | UP3000-HM10022 | UP3000-HM5042 | UP5000-HM8042 |
| Rated battery voltage | 24VDC | 48VDC |
| Battery input voltage | 21.6~32VDC | 43.2~64VDC |
| Max. battery charge current | 60A | 100A | 50A | 80A |
| Inverter Output |
| Continuous output power | 2000W | 3000W | 3000W | 5000W |
| Max. surge power (3s) | 4000W | 6000W | 6000W | 8000W |
| Output voltage | 220VAC(-6%~+3%), 230VAC(-10%~+3%) |
| Output frequency | 50/60±0.2% |
| Output waveform | Pure sine wave |
| Load power factor | 0.2-1 (load power ≤ continuous output power) |
| Total harmonics distortion (THD) | THD≤3% (resistive load) |
| 80% rated output efficiency | 92% | 92% | 92% | 92% |
| Max. rated output efficiency | 91% | 91% | 90% | 91% |
| Max. output efficiency | 93% | 93% | 93% | 93% |
| Switch time | 10ms (switch from the utility output to the inverter output) 15ms (switch from the inverter output to the utility output) |
| Utility Charging |
| Utility input voltage | 176VAC~264VAC(default), 90VAC～280VAC (programmable) |
| Utility input frequency | 40～65Hz |
| Max. utility charge current | 60A(when the utility input voltage is 90VAC~180VAC, the max. utility charge current is 30A) | 80A(when the utility input voltage is 90VAC~180VAC, the max. utility charge current is 40A) | 40A(when the utility input voltage is 90VAC~180VAC, the max. utility charge current is 20A) | 60A(when the utility input voltage is 90VAC~180VAC, the max. utility charge current is 30A) |
| Solar Charging |
| Max. PV open circuit voltage | 450V (at minimum environment temperature) 395V (25℃ environment temperature) | 500V (at minimum environment temperature) 440V (25℃ environment temperature) |
| MPPT voltage range | 80~350V | 120~400V |
| Max. PV input power | 2500W | 4000W | 4000W | 4000W |
| Max. PV charge power | 1725W | 2875W | 2875W | 4000W |
| Max. PV charge current | 60A | 100A | 50A | 80A |
| Equalization voltage | 29.2V (default AGM battery type) | 58.4V (default AGM battery type) |
| Boost voltage | 28.8V (default AGM battery type) | 57.6V (default AGM battery type) |
| Float voltage | 27.6V (default AGM battery type) | 55.2V (default AGM battery type) |
| Low voltage disconnect voltage | 21.6V (default AGM battery type) | 43.2V (default AGM battery type) |
| Tracking efficiency | ≥99.5% |
| Temperature compensate coefficient | -3mV/℃/2V (default) |
| General |
| Surge current | 50A | 60A | 56A | 95A |
| No-load consumption | < 1.8A | < 1.2A |
| Standby current | < 1.2A | < 0.7A |
| Mechanical Parameters |
| Dimensions (H×W×D) | 607.5×381.6×127mm | 642.5×381.6×149mm | 607.5×381.6×149mm | 642.5×381.6×149mm |
| Mounting size | 585×300mm | 620×300mm | 585×300mm | 620×300mm |
| Mounting hole size | Ø10mm | Ø10mm | Ø10mm | Ø10mm |
| Net weight | 15kg | 19kg | 18kg | 19kg |
| Enclosure | IP30 |
| Environment temperature | -20℃~50℃ |
